Specifications
| Printers | X-Max3 | X-Plus3 | X-Smart3 |
| Build Volume (W×D×H) |
325*325*315mm | 280*280*270mm | 175*180*170mm |
| Dimensions (W×D×H) |
553*553*601mm | 511*527*529mm | 370*362*397mm |
| Net weight (kg) |
30.2 | 24.3 | 10.5 |
| Printing Speed | ≤600mm/s | ≤500mm/s | |
| Extruder Flow: | 35mm³/s @PLA Matte(Model:150*150mm single wall; Material: PLA Rapido Matte;Temperature: 240℃) |
30mm³/s | |
| Extruder Temp | ≤350°C | ≤300°C | |
| Hotend (Included) | Copper alloy nozzle hotend For Common materials |
Brass Nozzle hotend |
|
| Hardened steel nozzle hotend For Abrasive materials |
|||
| Auxiliary Part Cooling Fan | ✔ | ✔ | ✖ |
| Chamber Temperature Control | 65°C Independent Chamber Heating | 65°C Independent Chamber Heating | ✖ |
| Chamber Circulation Fan With Activated carbon air filter |
✔ | Chamber Circulation Fan | Chamber Circulation Fan |
| Screen | 5.0 inch | 4.3 inch | |
| 800*480 touch screen | 480*272 touch screen | ||
| Seal print | Dryer Box + Desiccant | Optional | |
| Connection Options | 150M 2.4G Wi-Fi USB Flash Drive/Ethernet Cable |
150M 2.4G Wi-Fi USB Flash Drive |
|
| Rated Power | 900W | 800W | 350W |
| Recommended Filament | PAHT-CF,PET-CF,PA12-CF | PLA | |
| Compatible filament | PLA, ABS, ASA, PETG, TPU, PC, UltraPA, Nylon, etc. | ABS, ASA, PETG, TPU etc | |
| Structure | CoreXY | ||
| Z Axis： | Double Z axis | ||
| X axis | High-grade hardness steel linear hollow optical axis | Hardened Wear-resistant Carbon Fiber Rod | |
| Firmware: | Klipper | ||
| Printing Acceleration: | 20000mm/s² | ||
| Printing Accuracy: | ±0.1 mm | ||
| Filament diameter: | 1.75mm | ||
| Bed Leveling: | Automatic Leveling | ||
| Extruder transmission ratio | 9.5:1 | ||
| Hot end: | Ceramic Heating Core | ||
| Extruder: | High-flow Direct Drive Extruder | ||
| Nozzle diameter: | 0.4mm (0.2,0.6,0.8mm Optional) | ||
| Hot bed temperature: | ≤120℃ | ||
| Printing Plate: | Double-Sided Flexible Magnetic HF Plate | ||
| Filament Detection: | Yes | ||
| Resonance Compensation： | Yes | ||
| Pressure Advance： | Yes | ||
| Voltage: | 100-240VAC, 50/60Hz | ||
| Main Processor: | Cortex-A53,64-bit Processor | ||
| 1.5Ghz,8G-EMMC,1G DDR3 | |||
| Slicer: | QIDI Print and other third-party software, such as Ultimaker Cura, Simplify3D, PrusaSlicer, etc. | ||
| Operating System: | Windows, MacOS, Linux | ||
| Assembled | Assembled and First Print within 10 minutes | ||
